TH-4F Series Industrial Switch
The TH-4F Series Industrial Ethernet PoE Switch is the perfect power solution for SMBs looking to deploy Power over Ethernet networks. With its fan-less and energy-saving design, this switch offers reliable and efficient power delivery without the need for additional cooling.
The switch's compact size and easy maintenance make it a hassle-free solution that offers unparalleled reliability and security. Built to withstand harsh environments ranging from -30℃ to +75℃, the TH-4F Series switch is the ideal choice for transportation, factory floors, outdoor setups, and other low or high-temperature environments.
The TH-4F Series Industrial Ethernet PoE Switch guarantees uninterrupted industrial operation, ensuring that your business is always running smoothly. Plus, with its exceptional security features, you can rest assured that your network and data are safe from unauthorized access and cyber threats.
In addition, the TH-4F Series Industrial Ethernet PoE Switch offers unparalleled benefits, including reliable and efficient power delivery, compact size, easy maintenance, exceptional security, and reliable operation in harsh environments. Whether you're setting up a control cabinet in transportation or a factory floor, this switch is the perfect choice to ensure uninterrupted and secure operations.
● Complies with the IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at
● Auto- MDI/ MDI-X detection and negotiation in half-duplex/full-duplex modes for 10/ 100Base-TX RJ-45 port
● Features Store-and- Forward mode with wire-speed filtering and forwarding rates
● Supports packet size of up to 2K bytes
● Robust IP40 protection, fan-less design, high/low temperature resistance -30℃~ +75℃
● DC48V-58V input
● CSMA/CD protocol
● Automatic source address learning and aging
P/N | Fixed Port |
TH-4F0005P | 4*10/ 100Mbps Ethernet POE Port, Uplink 1*10/ 100Mbps |
TH-4F0008P | 8*10/ 100Mbps Ethernet POE Port |
TH-4F0104P | 4*10/ 100Mbps Ethernet PoE Port, 1*100Mbps SFP Port |
TH-4F0108P | 8*10/ 100Mbps Ethernet PoE Port, 1*100Mbps SFP Port |
TH-4F0204P | 4*10/ 100Mbps Ethernet PoE Port, 2*100Mbps SFP Port |
Provider Mode Ports | |
Power Interface | Phoenix terminal, Dual power input |
LED Indicators | PWR, Link/ACT LED/P1, P2/P1, P2/OPT |
Cable Type & Transmission Distance | |
Twisted-pair | 0- 100m (CAT5e, CAT6) |
Mono-mode Optical Fiber | 20/40/60/80/ 100KM |
Multi-mode Optical Fiber | 550m |
Network Topology | |
Ring Topology | Not support |
Star Topology | Support |
Bus TopologyTree Topology | SupportSupport |
Hybrid Topology | Support |
PoE Support | |
PoE Port | 1-4/1-8 |
PoE Standard | IEEE 802.3af, IEEE 802.3at |
Pin Assignment | 1, 2, 3, 6 |
Input Voltage | DC48-58V input |
Total Power ConsumptionLayer 2 Switching | <125W/<245W |
Switching Capacity | 14Gbps/1Gbps/ 1.4Gbps/1.8Gbps |
Packet Forwarding Rate | 0.744Mpps/ 1.33Mpps/10.416Mpps |
MAC Address Table | 1K/2K/8K |
Buffer | 512K/768K/1M |
Forwarding Delay | <4us/<5us |
MDX/ MIDX | Support |
Jumbo Frame |
Support 2K bytes/Support 2048 bytes/Support 10K bytes |
