TH-6G Series Unmanaged Industrial Gigabit Ethernet Switch
TH-6G Series Industrial Gigabit Ethernet Switch is a high-performance and reliable network switch specifically designed for harsh industrial environments.
It has the ability to operate in a wide temperature range of -40 to 75 ℃, making it ideal for use in extreme weather conditions.
This switch supports input power range from DC12V to 58V, and also features DIP switches for easy configuration, redundant power supply, and a watchdog function to ensure uninterrupted operation.
A watchdog is a feature that can automatically reset the switch in case of a system failure. TH-6G Series is an excellent choice for network connectivity in industrial settings such as factories, warehouses, or oil and gas fields.
● Complies with the IEEE 802.3, IEEE 802.3u
● Auto-MDI/MDI-X detection and negotiation in half-duplex/full-duplex modes for 10/100Base-TX RJ-45 port
● Features Store-and-Forward mode with wire-speed filtering and forwarding rates
● Supports packet size of up to 2K bytes
● Robust IP40 protection, fan-less design, high/low temperature resistance -30℃~ +75℃
● Wide power supply input DC12V-58V redundant
● CSMA/CD protocol
● Automatic source address learning and aging
| P/N | Description |
| TH-6G0005 | Unmanaged Industrial Switch, 5×10/100/1000M RJ45 Port |
| TH-6G0008 | Unmanaged Industrial Switch, 8×10/100/1000M RJ45 Port |
| TH-6G0016 | Unmanaged Industrial Switch, 16×10/100/1000M RJ45 Port |
| TH-6G0104 | Unmanaged Industrial Switch, 1x1000Mbps SFP Port, 4×10/100/1000M RJ45 Port |
| TH-6G0108 | Unmanaged Industrial Switch, 1x1000Mbps SFP Port, 8×10/100/1000M RJ45 Port |
| TH-6G0204 | Unmanaged Industrial Switch, 2x1000Mbps SFP Port, 4×10/100/1000M RJ45 Port |
| TH-6G0208 | Unmanaged Industrial Switch, 2x1000Mbps SFP Port, 8×10/100/1000M RJ45 Port |
| TH-6G0408 | Unmanaged Industrial Switch, 4x1000Mbps SFP Port, 8×10/100/1000M RJ45 Port |
