TH-6G0424 Industrial Switch 4xGigabit SFP, 24×10/100/1000Base-T
TH-6G0424 Industrial Ethernet Switch a high-performance, compact and reliable network switch designed for industrial applications with 4x Gigabit SFP and 16x 10/100/1000Base-T Ethernet ports. It is constructed with an IP40-rated metal case and has a wide operating temperature range of -40 to 75℃, making it ideal for use in harsh industrial environments. supports a range of advanced features such as Quality of Service (QoS), broadcast storm protection, Watchdog, and VLAN configuration. These features ensure reliable and efficient network communication and help to optimize network performance.
● Complies with the IEEE 802.3, IEEE 802.3u
● Auto-MDI/MDI-X detection and negotiation in half/full-duplex modes for 10/100/1000Base-TX RJ-45 port
● Features Store-and-Forward mode with wire-speed filtering and forwarding rates
● Supports packet size of up to 10K bytes
● Robust IP40 protection, fan-less design, high/low temperature resistance -40℃~ +75℃
● DC12V-58V input
● CSMA/CD protocol
● Automatic source address learning and aging
| P/N | Description |
| TH-6G0424 | Unmanaged Industrial Switch4x1000Mbps SFP Port, 24×10/100/1000M RJ45 Port |
| TH-6G0424P | Unmanaged Industrial PoE Switch4x1000Mbps SFP Port, 24×10/100/1000M RJ45 Port PoE |
